DIP Switch Selectable CCT & Wattages LED Downlights

These tunable white downlights come with a special LED driver featuring two DIP switches, allowing you to select different wattages and color temperatures within a single light. One light is equal to nine different ones, significantly reducing stock costs.

  • Input voltage: 220-240VAC 50/60Hz
  • Wattages: 5W to 40W selectable
  • Color temperature: selectable CCT range from 3000K, 4000K to 6000K.
  • Dimmable: No
  • Installation: Recessed mounted
  • Working life: >50000Hrs
  • Free flicker: Yes
  • Power factor: >0.9
  • Certificates: CE LVD EMC RoHS
  • Manufacturer warranty: 3/5Years
  • Working temp:-25/+55℃
  • Origin: Made in China
  • MOQ: 50pcs/Model

Order modelSelectable Watt by DIPDimensionCut outIP RateLumensSelectable CCT by DIP SwitchInput voltageDATASHEET
GR-DL-9WE (CCT)9W 7W 5Wø115×H50mmΦ95-100mmIP20550-950lm3000K/4000K/6500K selectable220-240VAC 50/60HzDownload
GR-DL-15WE (CCT)15W 12W 10Wø145×H50mmΦ120-130mmIP20110-1600lm3000K/4000K/6500K selectable220-240VAC 50/60HzDownload
GR-DL-25WE (CCT)25W 20W 18Wø191×H55mm170-175mmIP201800-2500lm3000K/4000K/6500K selectable220-240VAC 50/60HzDownload
GR-DL-9WB (CCT)9W 7W 5Wø110×H50mmΦ85-95mmIP20/IP44550-950lm3000K/4000K/6500K selectable220-240VAC 50/60HzDownload
GR-DL-12WB (CCT)12W 10W 8Wø120×H50mmΦ95-105mmIP20/IP44880-1300lm3000K/4000K/6500K selectable220-240VAC 50/60HzDownload
GR-DL-15WB (CCT)15W 12W 10Wø145×H57mmΦ115-130mmIP20/IP441100-1600lm3000K/4000K/6500K selectable220-240VAC 50/60HzDownload
GR-DL-25WB (CCT)25W 20W 18Wø191×H57mmΦ160-180mmIP20/IP441800-2500lm3000K/4000K/6500K selectable220-240VAC 50/60HzDownload
GR-DL-12WA-1 (CCT)12W 10W 8WØ115*48mmΦ95-100mmIP44880-1300lm3000K/4000K/6500K selectable220-240VAC 50/60HzDownload
GR-DL-15WA-1(CCT)15W 12W 10WØ138*H56mmΦ115-120mmIP441100-1600lm3000K/4000K/6500K selectable220-240VAC 50/60HzDownload
GR-DL-25WA-1(CCT)25W 20W 18WØ170*H62mmΦ150mmIP441800-2500lm3000K/4000K/6500K selectable220-240VAC 50/60HzDownload
GR-DL-40WN(CCT)40W 36W 25WØ230*H75mmΦ195-205mmIP402600-4200lm3000K/4000K/6500K selectable220-240VAC 50/60HzDownload

Materials & Finished

  • Body: aluminum body, matt white
  • Trim: Aluminum, white finished
  • Springs/Clips: Steel, high strength to fix onto the ceiling.
  • Covers: Only for SMD type, it is PC cover, frosted finish. glass cover for COB type

Control gear / led driver

  • Driver Brand: ZENYUAN Brand
  • Input voltage: 220-240VAC 50/60Hz
  • Output Voltage: 36VDC
  • THD:<15%
  • Efficiency:>87%
  • Power factor: >0.9
  • Free flicker: Yes
  • DIP switch: Yes, one DIP switch for selecting CCT, and another DIP Switch for selecting wattages.
  • IP Rating: IP22
  • Certificates: CE ENEC SAA CB
  • Warranty: 5Years

Photometric data

  • Light source brand: Bridgelux as standard, Osram available
  • Color rendering index:>80/90
  • Lumens:100lm-120lm/W output.
  • SDCM:<5
  • Beam angle: 110° Medium distribution
  • Lifetime:>50000Hrs
  • Low glare value: UGR<17
  • Color temperature:2700-2900K; 3000-3200K; 4000-4500K; 5700-6000K; 6000-6500K
  • Lumens maintenance: 99.9%@1000hrs/ 99%@3000hrs /98%@10000hrs. (LM80).
  • Emergency battery packs. ( emergency kits for 1-3Hours for 2-5Watt)

recessed downlight installation

Shopping malls, supermarkets, offices, retail stores, living rooms, bedrooms

Q: What is a CCT selectable downlight?

A: It is a kind of color-changing downlight, there is a DIP switch on the LED downlight or the LED driver, it is ok to select the color temperature range from 3000K to 4000k, then to 6000K. This means there are 3 different color temperatures in one LED light.
