Recessed Anti Glare Downlights 4/5/6/8inch | Model: GR-DL-B
GR-DL-B series recessed anti-glare downlights are designed with a deep reflector to be a low glare value. LED chips are located at the back of the downlight fittings and hidden deep inside the fitting. It can reduce the discomfort caused by the eyes looking directly at the light source. It is also better in appearance than the traditional E27/ G24/GU10 downlights are more modern. The lamp has a variety of color temperatures (3000K/4000K/6500K) to choose from, which can meet the needs of different indoor scenes and is widely used in residential areas, and commercial lighting.
Material and finished
- Housing: Aluminum body, brown powder-coated finished, round types. White frame and reflectors.
- Diffuser: Milky PC cover, Anti-UV. High light transmittance reaches more than 90%.
- Control gear: free flicker, Osram/Philips/DONE/BOKE/Eaglerise brand options.
- Light source: EPISTAR OR OSRAM SMD LED Chips, high CRI, high lumens output.
- PCB: 1.0mm thickness, High thermal conductivity double-sided aluminum substrate.
- Spring Clips: Iron body, strongest strength. Easy to do the recessed installation
Additional Options
- Zigbee/ WIFI Mesh Intelligent control by Phone APP, Google home, AMAZON Alexa.
- Dimming (Triac/0-10V/DALI Dimmable)
- Low voltage input voltage DC12V/DC24V/DC36V/DC48W
- Emergency kits (30% power with 1hours 2hours 3hours duration)
Electrical & Optical
- Working voltage:100-265VAC 50/60Hz or 220-240VAC 50/60Hz.
- Power Factor:>0.6 or >0.9
- THD:<20%
- Surge protection:1-2KV
- Color rendering index:>80 for EPISTAR, >90 for OSRAM Chips.
- Lumens:90lm-100lm/W output.
- SDCM:<5
- Efficiency:>89%
- IP Rating: IP22 Indoor use
- Beam angle: 60° Medium distribution
- Working temperature:-25℃/+55℃
- Compliance: CE RoHS Certified
- Warranty:2/3/5 Years.
Application
- Residential places like Living room, kitchen room, Bedroom.
- Commercial lighting: Hotels, Offices, Schools, Supermarkets, clothes stores.
GRNLED offers the best price in the market.
Models and Details
| Order model | Wattage | Dimension | Cut out | Lumens | Color temperature | UGR | Chips | CRI(Ra) | Input voltage | DATASHEET |
| GR-DL-12WB | 12W±5% | Ø130*H60mm | 110mm-115mm | 1000-1200mm | 3000K Warm white; 4000K Daylight;6500K Cool white | <19 | EPISTAR or Osram SMD LED | >80 | 110-120VAC/220-240VAC 50/60Hz | Download |
| GR-DL-15WB | 15W±5% | Ø165*H65mm | 140mm-145mm | 1350-1500lm | 3000K Warm white; 4000K Daylight;6500K Cool white | <19 | EPISTAR or Osram SMD LED | >80 | 110-120VAC/220-240VAC 50/60Hz | Download |
| GR-DL-18WB | 18W±5% | Ø185*H80mm | 160mm-165mm | 1650-1800lm | 3000K Warm white; 4000K Daylight;6500K Cool white | <19 | EPISTAR or Osram SMD LED | >80 | 110-120VAC/220-240VAC 50/60Hz | Download |
| GR-DL-24WB | 24W±5% | Ø225*H90mm | 200mm-205mm | 2150-2400lm | 3000K Warm white; 4000K Daylight;6500K Cool white | <19 | EPISTAR or Osram SMD LED | >80 | 110-120VAC/220-240VAC 50/60Hz | Download |
| GR-DL-30WB | 30W±5% | Ø225*H90mm | 200mm-205mm | 2700-3000lm | 3000K Warm white; 4000K Daylight;6500K Cool white | <19 | EPISTAR or Osram SMD LED | >80 | 110-120VAC/220-240VAC 50/60Hz | Download |
