High Power High bay Light | Model: GR-HB-T
The high power high bay led lighting is powerful in brightness, They provide energy-efficient, ultra-high lumen light output equivalent to traditional HID lighting at a fraction of the wattage. They can deliver 200000lm Max, which is a perfect choice for big locations which more than 100-f00t mounting height. The highest-grade LED components and driver brand are protected from dust and moisture by waterproof connections and silicone seals for an IP65 rating. Widely used for construction sites, football fields, high mast at squares.
- Philips/Osram led chips, highest brightness up to 140lm/W output Max.
- Aluminum housing provides superior thermal management for the Led chips, extending the lifetime of high bay lighting
- Engineered for high efficiency, extreme mounting heights, and performance in the most challenging high-bay applications
- High performance led drivers with surge protection devices, protection grade up to 6KV.
- Surface mounted/Suspension mounted/Wall mounted are all available.
- Working life up to 10years.
- CE RoHS certified.
- Voltage: 100-277V 50/60Hz
- Operating temperature: -30°C to +55°C (-30°F to +124°F).
- Power factor:>0.95
- Extreme Mounting-Heights
- Convention Centers
- Aircraft Manufacturing
- Construction sites
- Photocell (Dusk to dawn)
- Dimming (PWM/0-10V/DALI dimmable)
- DC12V/24V/36V/48V input solution
GRNLED offers the best price in the market. Better quality but lower price.
Models and Details
|Order model||Wattage||Dimension||Lumens||Color temperature||Beam angle||CRI||IP Rating||IK Rating||Working life||DATASHEET|
|GR-HB-300WT||300W±5%||453*310*260mm||33000-39000lm||2700K-3000K WW, 4000K-4500K NW, 6000-6500K CW||60°/90°||>80||IP65||IK08||>50000Hrs||Download|
|GR-HB-400WT||400W±5%||496*420*310mm||44000-54000lm||2700K-3000K WW, 4000K-4500K NW, 6000-6500K CW||60°/90°||>80||IP65||IK08||>50000Hrs||Download|
|GR-500WT||500W±5%||496*420*354mm||55000-65000lm||2700K-3000K WW, 4000K-4500K NW, 6000-6500K CW||60°/90°||>80||IP65||IK08||>50000Hrs||Download|
|GR-HB-700WT||700W±5%||D508*H433mm||80000-90000lm||2700K-3000K WW, 4000K-4500K NW, 6000-6500K CW||25°/60°/90°||>80||IP65||IK08||>50000Hrs||Download|
|GR-HB-1000WL||1000W±5%||D558*H630mm||120000-130000lm||2700K-3000K WW, 4000K-4500K NW, 6000-6500K CW||45°/60°||>80||IP65||IK08||>50000Hrs||Download|
|GR-HB-1500WL||1500W±5%||D653*H630mm||165000-200000lm||2700K-3000K WW, 4000K-4500K NW, 6000-6500K CW||45°/60°||>80||IP65||IK08||>50000Hrs||Download|
*Order Model: GB-HB-300WT = GB-HB-T Model for 300 Wattage
