Linear Wall Washer Lights | Model: GR-WW-A

GR-WW-A Series is our outdoor linear wall washer lights, mainly used for façade lighting for exterior walls. Its length is 500mm and 1000mm as standard, but it is ok to customize different lengths such as 300mm 400mm 600mm 800mm if needed. Available 3000K,6500K, Red, Blue, Green, RGB in color temperatures for different requirements.

Materials & Finished

  • Housing: Die-cast aluminum body, silver/aluminum color.
  • Cover: 4mm thickness toughed glass cover, clear.
  • Lens: PMMA optical lens,30° beam angle as standard.
  • Led chips: Bridgelux high power chips, good brightness.
  • Driver: Built-in DONE Brand driver, top quality.
  • Bracket: Aluminum brackets, 180° rotation
  • Cable: 15-500cm length cable available, with waterproof connector option.

Additional Options

  • Dimmable (PWM/0-10V/DALI)
  • DC24V or DC12Volt.
  • DMX512
  • Remote controller
  • Different length

Electrical & Optical

  • Input voltage: 100-240VAC 50/60Hz
  • Color rendering index:>80
  • SDCM:<5
  • Efficiency:>89%
  • IK level: IK07
  • IP Rating: IP66 outdoor use
  • Beam angle: 30°
  • Working life:>50000Hrs
  • Color temperature: 3000K-6500K Cold white/RGB
  • Working temperature:-25℃/+60℃
  • Compliance: CE RoHS Certified
  • China Manufacturer Warranty:2/3/5Years.

GRNLED offers the best price in the market.

Models and Details

Order ModelWattagesDimensionLumensIP RateIK RatingColor temperatureInput voltageWorking lifeDatasheet
GR-WW-9WA9WL500*W46*H46mm800-900lmIP66IK073000K/4000K/6500K/Red/Green/Blue/RGB110-120V/220-240VAC>50000HrsDownload
GR-WW-12WA12WL500*W46*H46mm1060-1200lmIP66IK073000K/4000K/6500K/Red/Green/Blue/RGB110-120V/220-240VAC>50000HrsDownload
GR-WW-18WA18WL1000*W46*H46mm1660-1800lmIP66IK073000K/4000K/6500K/Red/Green/Blue/RGB110-120V/220-240VAC>50000HrsDownload
GR-WW-24WA24WL1000*W46*H46mm2150-2400lmIP66IK073000K/4000K/6500K/Red/Green/Blue/RGB110-120V/220-240VAC>50000HrsDownload
GR-WW-36WA36WL1000*W46*H46mm3300-3600lmIP66IK073000K/4000K/6500K/Red/Green/Blue/RGB110-120V/220-240VAC>50000HrsDownload
